Product Name :Energy Saving 2KW/5KW Heating Capacity DA12V/24V
Integrated Truck Parking Heater Unit
Brief Introduction :
- The parking heater is an in-vehicle heating device which is
independent from the vehicle engine.
- It has its own fuel pipe,electric circle,combustion heating and
control panel, etc.
- When the vehicle is parking, driver can use this parking heater
to warm ip the cold environment of cab without starting the engine.
- It can be installed under truck seat or any other place .
- It can work under high altitude mountain environment
- Integrated type has all in one unit, oil tank and control panel
all together, easy install.
Main Parameters :
| Heating power | 2000-5000W |
| Fuel | Diesel |
| Oil tank | 10L |
| Rated Voltage | 12V | 24V |
| Working power | 20-50W |
| Rated power | 15-90W |
| Min voltage | 9W | 17W |
| Max voltage | 19W | 32W |
| Fuel consumption (1/h) | 0,12-0.43 | 0.12-0.5 |
| Working Temperature | -40℃ ~ 76℃ |
| Inside noise | less than 78dBA |
| Overheat protection | 180 ℃ |
Dimension:
Main Features :
1. Preheating the cabin air very quickly after hot start
2. Keep heating 48hours when vehicle parking
3. Lower power consumption - the ideal heating method for longtime
parking
4. Lower fuel consumption (0.1 liters of oil per hour)
5. Can set the cabin temperature
6. The temperature in the cabin is steplessly adjustable
7. Reduce noise by controlling blower speed
8. Optional internal or external installation
9. Real-time function monitoring and diagnostic system
10. Maintenance free, easy maintenance
Button and display function:
Applications :
Parking heater can be used in any vehicle cab with diesel fuel .
Shipping Packing :
We pack the parking heater with carbon box then on pallet
For shipment we can arrange complete supply chain, start from our
factory to customer's factory. and also we support customer to do
custom clearance and local transportation
Our parking heater and parking air conditioners
we have split type parking heater, integrated type and split type
parking air conditioner also.
Attention of installation and use
1. the air inlet must not be covered by anything
2. the air inlet must avoid dust inhaled
3. the exhaust outlet must be installed outside of the vehicle to
prevent the exhaust gas from entering the driver's cab
through ventilation device, warm air inlet or window
4. use national standard diesel oil, poor quality diesel oil easy
to form carbon deposit on the surface of the burner
5. replace the atomization net once a year
6. empty the oil tank if not going to use it for a long time , for
example during summer season.
Our Certificate:
